LS3 Rectangle Port Carb Conversion Holley 300-129 Dual Plane Intake/MSD 6014 Box

Description

Product Description

This listing is for an MSD/Holley Intake Manifold/Ignition Controller Kit for GM LS Engines with Rectangle Port Cylinder Heads such as LS2/L92 Style; Works with 24x with 1x Cam Sensors and 54x with 4x Cam Sensors Included components: Holley Dual Plane Intake part 300-129 – Includes Intake Seals MSD Programmable Ignition Controller part 6014 (Includes Harness)

Note! This kit will not fit with the 24x reluctor wheel when a 4x Cam gear is swapped, but a separate harness is available to adapt that, MSD P/N 2279

We put this kit together at SK Speed to simply the install of a Carburetor on a Cathedral Port LS Engine. With Holley Dual Plane Intake, you get a standard 4150 Flange which accepts most aftermarket Carburetors.  The MSD 6014 Ignition Controller allows a simple plug-n-play installation affording easy control over the factory coils. The controller is also programmable giving total ignition control when needed.

Features

1500-6500 RPM power band

4150 Square bore flange

Optimized runner layout and constant cross sectional area – broad torque curve, best vehicle performance from 1500-6500 RPM

Minimum carb flange height – fit in vehicles with minimum hood modifications

Cast aluminum construction – great manifold for carbureted or throttle body EFI street applications

Efficient casting design – lightweight, consistent wall thicknesses, improved casting quality

Includes Intake Bolts as well as O-Ring Port Seals

MSD Ignition Controller

As the popularity of GM LS engines continue to grow, so does the demand for a powerful, reliable and easily adaptable ignition system. MSD has answered this demand with an updated and improved version of the popular 6LS box. Whether using a stock crate engine or building a custom powerhouse, the MSD LS Ignition provides the control you need to achieve the performance you want. Dial in the perfect tune for your LS using the easily adjustable preset timing curves or hookup to your computer and program a custom setup with our user friendly MSD View software. New features of the LS Ignition include; high speed data acquisition, an optional coolant temperature sensor input, idle timing control, as well as individual cylinder timing. These features are in addition to the existing programmable step retard, launch retard and RPM rev limiters from its predecessor.

Features:

• Fits most LS Engines

• No PC required for basic functionality

• Six preprogrammed timing tables for easy set-up

• Rotary selector switch allows timing changes on the fly

• Nitrous and boost compatible

• High speed data acquisition

• Fully Sealed direct plugin connectors

• Programmable step retard

• Launch and max rev limiters

• Optional coolant temperature sensor input

• Launch retard

• Idle timing control

• Individual cylinder timing

• Compatible with all MSD, Accel and GM LS coils

1. Can be installed on both 24x and 58x crank trigger engines

2. Use on carbureted or fuel injected engines

3. Does not control fuel

4. Optional coolant temperature sensor GM PN 12608814

Looking for an Edelbrock manifold instead ?

Edelbrock Manifold E1171197 is a comparable option.

Kits with MSD boxes and Made in the USA Edelbrock manifolds are available as well.

EZKLS1018 or EZKLS1019
